The RT2518 is a high performance positive voltage regulator designed for applications requiring ultra-low input voltage and ultra-low dropout voltage at up to 1.2 amperes. It operates with an input voltage as low as 1.4V, and the output voltage is adjustable as low as 0.5V. The RT2518 features ultra low dropout, ideal for applications where output voltage is very close to input voltage. Additionally, the RT2518 has an enable pin to further reduce power dissipation while shutdown. The RT2518 provides excellent regulation over variations in line, load and temperature. The RT2518 is available in the WDFN-8L 3x3 package.


  • Telecom/Networking Cards
  • Motherboards/Peripheral Cards
  • Industrial Applications
  • Wireless Infrastructures
  • Set-Top Boxes
  • Medical Equipments
  • Notebook Computers
  • Battery Powered Systems
Key Spec.
Status Active
Vin (min) (V) 1.4
Vin (max) (V) 6
Vout (min) (V) 0.5
Vout (max) (V) 5.5
Output Adj. Method Resistor
Accuracy (+/- %) 1.5
Iout (max) (mA) 1200
Iq (typ) (uA) 700
Vdropout @ rated current (typ) (mV) 120 @ 1.2A
Bias Rail No
Cout Type Ceramic
Charge Pump Yes
Features Enable Input;Industrial;Low Dropout;OCP;Stable with Ceramic Capacitor
Package Type WDFN3x3-8
  • Input Voltage as Low as 1.4V
  • Ultra-Low Dropout Voltage 200mV @ 1.2A
  • Adjustable Output Voltage from 0.5V to 5.5V
  • Over-Current Protection
  • Over-Temperature Protection
  • 1μA Input Current in Shutdown Mode
  • Enable Control
