The RT7084C2M is an application-specific IC designed for PMSM/BLDC motor applications. This two-in-one ASIC integrates several functional circuits, including a 3-phase motor controller, a 3-phase gate driver, three bootstrap diodes, a 5V LDO, and a buck converter.<br />The RT7084C2M embeds the ARM 32-bit Cortex-M0 core with peripheral circuits to perform sensorless Field Oriented Control (FOC). In addition, this ASIC provides several system-level peripheral functions, including filters at the ADC input, a communication interface, a thermal sensor, short circuit protection (SCP) and locked-rotor protection, to reduce component count, PCB size and system cost.<br />Moreover, the RT7084C2M drives external N-Channel MOSFETs in a three half-bridge configuration with built-in bootstrap circuitry.<br />The RT708<span>4C</span>2M is available in a VQFN-32L 4x4 package. The recommended junction temperature range is -40°C to 125°C, and the ambient temperature range is -40°C to 105°C.
3
RT7084C2M Typical Circuit
anchor
productDetailSection
i18n(anchor-tab.product-detail-section.title)
productDetailSectionAnchorTab
orderingInformationSection
i18n(anchor-tab.ordering-information-section.title)
orderingInformationSectionAnchorTab
technicalDocumentationSection
i18n(anchor-tab.technical-documentation-section.title)
technicalDocumentationSectionAnchorTab
designToolSection
i18n(anchor-tab.design-tool-section.title)
designToolSectionAnchorTab
applicationSection
i18n(anchor-tab.application-section.title)
applicationSectionAnchorTab
supportSection
i18n(anchor-tab.support-section.title)
supportSectionAnchorTab
24
24
24
24
i18n(tabs.product-detail.title)
productDetailTabs
i18n(tab-item.parameter-section.title)
parameterSection
parameterSectionTab
i18n(tab-item.package-size-pin-size-section.title)
packageSizePinsSizeSection
packageSizePinsSizeSectionTab
i18n(tab-item.product-feature-section.title)
productFeatureSection
productFeatureSectionTab
24
24
24
24
buttonSeeProductDifferences
text-with-icon
right
secondary-m
tertiary
i18n(button-item.see-product-differences.button-label)
i18n(button-item.see-product-differences.button-link)
_self
false
buttonFindOtherCategory
text-with-icon
right
secondary-m
tertiary
i18n(button-item.find-other-category.button-label)
i18n(button-item.find-other-category.button-link)
_self
false
32
32
32
32
scrollable-table
parameterTable
normal-table
table-group
package-size-pins-size
packageSizePinsSizeTable
productFeature
<div class="spec-list"><ul class="lv1"><li>Integrates 3-Phase PMSM/BLDC Controller, Gate Driver, Bootstrap Diodes, 5V LDO, and Gate Driver LDO </li><li>Input Voltage Range: 16V to 80V </li><li>Sensorless, Sine-Wave Field Oriented Control (FOC) </li><li>Integrates Filters at ADC Input </li><li>Protections: SCP, UVLO, Locked-Rotor, and Thermal Detection </li><li>PMSM/BLDC Motor Controller- ARM 32-bit Cortex-M0 CPU, Frequency up to 60MHz- Memories Size: 16kB MTP, Internal ROM with Embedded Motor Control Library and 4kB SRAM- Power Management: Deep Sleep- Communication Interface: I<sup>2</sup>C and UART- Configurable ADC Gain: x1, x4, and x8- 5-Channel 12-Bit ADC- AD0 to AD3 for Differential Mode Current Sense- AD6 to AD8 for System Application - 1-Channel Voltage Type 8-bit DAC </li><li>Gate Driver- Floating Channel Designed for Bootstrap Operation- Sourcing/Sinking Current: 100mA/200mA- Built-In UVLO Functions for All Channels- Matched Propagation Delays for All Channels </li><li>VQFN-32L 4x4 Package </li></ul></div>
24
24
24
24
i18n(tabs.ordering-information.title)
orderingInformationTabs
i18n(tab-item.product-section.title)
productSection
productSectionTab
i18n(tab-item.evb-section.title)
evbSection
evbSectionTab
i18n(tab-item.ordering-detail-section.title)
orderingDetailSection
orderingDetailSectionTab
24
24
24
24
productImageSwitcher
RT7084C2M Ordering Information
normal-table
card-list
products
productTable
evbImageSwitcher
normal-table
card-list
evb
evbTable
orderingDetail
technical-documents
RT7084C2M
technicalDocumentMultipleTable
design-tools
RT7084C2M
designToolMultipleTable
32
56
56
56
rt-blue-800
i18n(text.application-title.text-content)
applicationTitle
withLine
24
24
24
24
<div class="spec-list"><ul class="lv1"><li>Server Fan </li><li>Telecom Fan </li><li>Liquid Pump </li></ul></div>
