productFeature

<div class="spec-list"><ul class="lv1"><li>AEC-Q100 Grade 1 Qualified </li><li>Compliance with ISO 26262 ASIL B </li><li>Power-On Built-In Self-Test (BIST) for OV/UV Monitor, I²C Cyclic Redundancy Check (CRC), and OTP Register CRC Protection </li><li>Three Step-Down Converters (HVBuck1, LVBuck2, and LVBuck3) with Peak-Current Mode PWM Operation and PSM Mode for Sentry Mode via I²C Setting <ul class="lv2"> <li></li><li>Fixed Switching Frequency at 2.1MHz </li><li>EMI Reduction Features including Spread Spectrum and Phase-Shift Operation </li><li>HVBuck1 Supports Input Voltage from 4V to 24V with 36V Load Dump Protection, Adjustable Output Voltage, and up to 1.5A Output Current </li><li>LVBuck2 and LVBuck3 Support Input Voltage from 2.7V to 5V, Adjustable Output Voltage, and up to 1.5A Output Current </li><li>Float LVBuck2/LVBuck3 Related Pins for Unused Channels </li></ul> </li><li>Two Low-Dropout Regulators (LDO1 and LDO2) <ul class="lv2"> <li></li><li>LDO1 with 2.7V to 5V Input Voltage, Adjustable Output Voltage, up to 0.3A Output Current, and High PSRR with 0.1A Output Current (60dB at 100kHz, 40dB at 1MHz) </li><li>LDO2 with 2.7V to 5V Input Voltage, Adjustable Output Voltage, and up to 0.4A Output Current </li></ul> </li><li>Input and Output Functions <ul class="lv2"> <li></li><li>Sequence Control for External IC via SEQOUT </li><li>Power Status Indication via PGOOD </li><li>Error Status Indication via ERROUT </li><li>Two Error Signal Receivers via ERRIN1/ERRIN2 </li><li>External Voltage Monitor via VMONIN </li></ul> </li><li>Small Form Factor <ul class="lv2"> <li></li><li>Wettable WET-WQFN-24AL 4x4 Package with Compact BOM </li></ul> </li><li>Junction Temperature Range: -40°C to 150°C </li><li>Ambient Temperature Range: -40°C to 125°C </li></ul></div>
