The RTQ6060 series comprises high-precision current monitors that are commonly used in most current-reporting systems and current-sensing circuits for precision current measurement and system optimization. These devices can sense a low-voltage drop (10mV) across the shunt resistor at a common-mode voltage ranging from -0.3V to 36V. They feature extremely low input offset, offset drift, gain error, and gain drift, all of which are achieved by zero-drift architecture. Six fixed gains of 50, 75, 100, 200, 500, and 1000V/V are available to accommodate different current scaling applications.These devices operate from a single power supply ranging from 2.7V to 36V and draw a maximum supply current of 100μA. The RTQ6060 is available in an SC-70-6 package.The recommended ambient temperature range is -40°C to 125°C.
RTQ6060 Typical Circuit
