The RTQ9154-QA is an ultra-low output noise, high- efficiency, four-channel class-D audio power amplifier. It delivers 4x27W into 4Ω at 10% THD+N from a 14.4V supply in automotive applications. It can achieve over 86% power efficiency with an output switching frequency of up to 2.1MHz for clarity, which enables a cost-optimized solution in a very small PCB size. Additionally, the RTQ9154-QA can be set either above the AM band, which eliminates the AM-band interference and reduces output filter size and cost, or below the AM band to optimize efficiency.The RTQ9154-QA is fully configurable through the I<sup>2</sup>C bus interface and features comprehensive diagnostics array specially designed for automotive applications.Its built-in protection circuits provide thermal fold-back, over-temperature, overcurrent, overvoltage, and undervoltage protections and report error status.The RTQ9154-QA is a 3-wire device that receives all clocks from external sources with standard I<sup>2</sup>S and TDM (Time-Division Multiplexing) formats. It supports a wide range of input sampling rates from 32kHz to 192kHz. The device is offered in a 56-pin RTSSOP package with the exposed thermal pad facing up.The recommended junction temperature range is -40°C to 150°C, and the ambient temperature range is -40°C to 125°C.
RTQ9154-QA Typical Circuit
anchor
productDetailSection
i18n(anchor-tab.product-detail-section.title)
productDetailSectionAnchorTab
orderingInformationSection
i18n(anchor-tab.ordering-information-section.title)
orderingInformationSectionAnchorTab
technicalDocumentationSection
i18n(anchor-tab.technical-documentation-section.title)
technicalDocumentationSectionAnchorTab
designToolSection
i18n(anchor-tab.design-tool-section.title)
designToolSectionAnchorTab
applicationSection
i18n(anchor-tab.application-section.title)
applicationSectionAnchorTab
supportSection
i18n(anchor-tab.support-section.title)
supportSectionAnchorTab
24
24
24
24
i18n(tabs.product-detail.title)
productDetailTabs
i18n(tab-item.parameter-section.title)
parameterSection
parameterSectionTab
i18n(tab-item.package-size-pin-size-section.title)
packageSizePinsSizeSection
packageSizePinsSizeSectionTab
i18n(tab-item.product-feature-section.title)
productFeatureSection
productFeatureSectionTab
24
24
24
24
buttonSeeProductDifferences
text-with-icon
right
secondary-m
tertiary
i18n(button-item.see-product-differences.button-label)
i18n(button-item.see-product-differences.button-link)
_self
false
buttonFindOtherCategory
text-with-icon
right
secondary-m
tertiary
i18n(button-item.find-other-category.button-label)
i18n(button-item.find-other-category.button-link)
_self
false
32
32
32
32
scrollable-table
parameterTable
normal-table
table-group
package-size-pins-size
packageSizePinsSizeTable
productFeature
<div class="spec-list"><ul class="lv1"><li>AEC-Q100 Grade 1 Qualified </li><li>I<sup>2</sup>S and TDM Input </li><li>4x22W, THD + N = 1%, 4Ω, 14.4V BTL </li><li>4x27W, THD + N = 10%, 4Ω, 14.4V BTL </li><li>2x45W, THD + N = 10%, 2Ω, 14.4V PBTL </li><li>THD + N is 0.03% </li><li>SNR up to 115dB </li><li>Ultra-Low Quiescent Current Mode </li><li>Ultra-Low Noise = 18μV </li><li>Switching Frequency up to 2.1MHz </li><li>Sampling Frequency from 32kHz to 192kHz </li><li>I<sup>2</sup>C Control with 16 Address Options </li><li>Built-In Thermal Fold-Back and Clip Detection </li><li>Load Diagnostics - Output Open Load and Short Load - Output Short to Ground or Power - DC and AC Coupled Load Detection </li><li>Protection Features - Output Short-Circuit - Overvoltage and Undervoltage - Overcurrent Warning and Protection - Over-Temperature - DC Protection - 40V Load Dump </li><li>Ambient Temperature Range: -40°C to 125°C </li><li>Ambient Temperature Range: -40°C to 125°C </li></ul></div>
24
24
24
24
i18n(tabs.ordering-information.title)
orderingInformationTabs
i18n(tab-item.product-section.title)
productSection
productSectionTab
i18n(tab-item.evb-section.title)
evbSection
evbSectionTab
i18n(tab-item.ordering-detail-section.title)
orderingDetailSection
orderingDetailSectionTab
24
24
24
24
productImageSwitcher
RTQ9154-QA Ordering Information
normal-table
card-list
products
productTable
evbImageSwitcher
normal-table
card-list
evb
evbTable
orderingDetail
technical-documents
RTQ9154-QA
technicalDocumentMultipleTable
design-tools
RTQ9154-QA
designToolMultipleTable
32
56
56
56
rt-blue-800
i18n(text.application-title.text-content)
applicationTitle
withLine
24
24
24
24
<div class="spec-list"><ul class="lv1"><li>Automotive Head Units </li><li>In-Vehicle Infotainment </li></ul></div>
