RT8498

18V, 具调光控制的多架构 LED 驱动器

RT8498
New

RT8498为支持3V~18V宽输入电压范围及输出电压可达18V的电流模式LED驱动器。内置350kHz操作频率，外部PWM电感和输出/输入电容的尺寸可最小化。藉由100mV电流感测控制达到高效率。LED调光控制可以经由模拟或PWM信号完成。RT8498提供内置软启动功能避免冲击电流和过热关机以防止设备过热。
RT8498采用SOT-23-6封装。

应用

  • GPS, 便携式DVD背光源
  • 展示灯和室内照明
  • IP摄像机

主要规格

RT8498
Status Active
Vin (min) (V) 3
Vin (max) (V) 18
Vout (max) (V) 18
LED Channels 1
Topology Boost;Buck;Buck-boost
SW Freq (typ) (kHz) 350
Vcs (typ) (mV) 100
Dimming Control Analog;PWM;PWM-to-Analog
Features Current Mode Control;Cycle-by-Cycle Current Limit;OVP
Package Type SOT-26

关键特性

  • 高电压:VIN可达18V, VOUT可达18V

  • 内建2A电源开关

  • 电流模式PWM控制

  • 350kHz固定开关频率

  • 模拟、PWM数字或PWM转换模拟与一个外部的电容

  • 内置软启动避免冲击电流

  • 欠压锁定

  • 内置过压保护以限制输出电压

  • 逐周期电流限制

  • 过热关机
