RT9740A 是一个具有致能脚位、小体积、超低 RON 的双通道负载开关。产品内含两个 N-MOSFET，可操作在输入电压范围从0.8V至5.5V，且单一通道最大电流可输出6A。每一个开关皆独立由致能脚位 (EN1和EN2) 控制，可直接和低电压控制讯号连接。RT9740A 提供WDFN-14TL 3x2 封装。
集成双通道负载开关
输入电压范围： 0.8V至5.5V
超低 RON 阻抗 ► RON = 18mΩ at VIN = 5V (VDD = 5V) ► RON = 18mΩ at VIN = 3.6V (VDD = 5V) ► RON = 18mΩ at VIN = 1.8V (VDD = 5V)
每通道6A 最大连续开关电流
低静态电流 ► 75μA (双通道) ► 55μA (单通道)
启动电压最低可以使用 1.4V/1.8V/2.5V/3.3V
可配置的上升时间
快速输出放电 (QOD)
自适应放电电流
14T引脚WDFN封装与散热垫
符合 RoHS 标准及不含卤素
