The RT8088A is a full featured 5.5V, 3A, Constant-On-Time (COT) synchronous step-down converter with two integrated MOSFETs. The current mode COT operation with internal compensation allows the transient response to be optimized over a wide range of loads and output capacitors to efficiently reduce external component count. The RT8088A provides up to 2.7MHz switching frequency to minimize the size of output inductor and capacitors. The output voltage is programmed through an I2C interface capable of operating up to 400kHz. The RT8088A is available in the WL-CSP-15B 1.31x2.11 (BSC) package.
2.5V to 5.5V Input Voltage Range
Current Mode COT Control Loop Design
Fast Transient Response
Internal 48mΩ and 22mΩ Synchronous Rectifier
I2C compatible interface up to 400kHz
Highly Accurate VOUT Regulation Over Load/Line Range
Robust Loop Stability with Low-ESR COUT
RoHS Compliant and Halogen Free
