應用

主要規格
RT9611C RT9611D
Status Active Active
Number of Channels 1 1
Vcc (typ) (V) 12 12
UGATE Rise Time (typ) (ns) 25 25
UGATE Fall Time (typ) (ns) 12 12
LGATE Rise Time (typ) (ns) 24 24
LGATE Fall Time (typ) (ns) 10 10
UGATE Sink Resistance (typ) (Ohm) 1.4 1.4
LGATE Sink Resistance (typ) (Ohm) 1.1 1.1
Disable Pin Yes Yes
Built-In Bootstrap Diode Yes Yes
Iq (typ) (mA) 1.2 1.2
Features Tri-State Input Tri-State Input
Package Type WDFN3x3-8 WDFN3x3-8
Outline Dimension, Footprint, Drawing Download Download
關鍵特性
Datasheet
TitleVersionLast UpdateDownload
RT9611C/RT9611D: Initial Release2013/11/07
Part NumberPackage TypePackage Qty.Free SampleDistributorStockBuy From Authorized Distributor
RT9611CGQWWDFN3x3-81,500 Request Digikey 1,048 Buy
Mouser 1,490 Buy
庫存實際狀況請洽代理商或業務窗口
