productFeature

<div class="spec-list"><ul class="lv1"><li>Single-Chip WPC V1.2.4 Compliant Receiver </li><li>Integrated Synchronous Rectifier Switch <ul class="lv2"> <li></li><li>Support Output Power up to 15W </li><li>High Rectifier Efficiency Up to 97% </li><li>High System Efficiency Up to 83% </li><li>Programmable Loading for Synchronous Rectifier Operation </li></ul> </li><li>Programmable Dynamic Rectifier Voltage Control for Optimized Transient Response and Power Efficiency </li><li>High Accurate Received Power Calculation for FOD Function <ul class="lv2"> <li></li><li>12-bit ADC for Voltage/Current Measurement </li><li>Coil Power Loss Modeling for Optimized Compensation </li><li>Adaptive Power Offset Compensation </li></ul> </li><li>Low Quiescent Embedded 32-bit ARM Cortex-M0 MCU <ul class="lv2"> <li></li><li>32kB ROM/OTP, 1kB SRAM, 272B MTP and ROM 4kB (Boot Loader) </li><li>Easy Tuning for Communication and Control Parameters </li></ul> </li><li>Support Bi-direction Channel Communication <ul class="lv2"> <li></li><li>FSK Demodulation for Power Signal from Wireless Power Transmitter </li><li>ASK Modulation for Power Signal to Wireless Power Transmitter </li></ul> </li><li>Programmable Temperature Control </li><li>Programmable Charge Status Packet </li><li>Support Alignment with Transmitter </li><li>Support Enable, Charge Complete and Fault Control Inputs </li><li>Receiver Controlled EPT Packet </li><li>Over-Current Limit </li><li>Over-Voltage Protection </li><li>Thermal Shutdown </li><li>CSP 3.4mm x 3.2mm 56B (Pitch = 0.4mm) </li><li>Low Profile (0.5mm Max.) </li></ul></div>
