RT3635BT 是一款符合 IMVP9.2 规范的 CPU 电源控制器，具备三组电压轨：用于 VCCCORE VR 的 5 相同步降压控制器、用于 VCCGT VR 的 2 相同步降压控制器，以及用于 VCCSA VR 的 1 相同步降压控制器。每组电压轨的输出皆可配置为支援所需的相位分配，最高为 VCCCORE 5 相、VCCGT 2 相及 VCCSA 1 相。例如，RT3635BT 支援 5+2+1、4+2+1、3+2+1 等输出配置。RT3635BT 整合 Smart Phase Management（SPM）功能，以在所有负载范围内达到最高效率。它具备可由使用者透过 I<sup>2</sup>C 协定介面设定的自动加相或减相阈值。RT3635BT 采用 G-NAVP<sup>TM</sup>（Green Native AVP），这是 Richtek 专有的拓扑架构，由具有限 DC 增益的 EA 放大器结合电流模式控制所衍生。这可轻松设定 droop，以满足所有 Intel CPU 对 AVP（Adaptive Voltage Positioning）的要求。基于 G-NAVP<sup>TM</sup> 拓扑，RT3635BT 具备新一代快速反应机制（Adaptive Quick Response, AQR），可在负载暂态期间优化 AVP 效能并降低对输出电容的需求。该元件支援跨多种操作状态的模式转换功能，并内建序列 VID（SVID）介面，可与符合 Intel IMVP9.2 规范的 CPU 通讯。RT3635BT 支援 baby phase（Heterogeneous Phase）功能，透过在第 1 相使用额定值相对较小的功率元件，以及较大的电感值与电阻值，以提升轻载效率。RT3635BT 提供内建非挥发性记忆体（NVM），用于储存平台设定，例如 ICCMAX、切换频率或 AQR 触发位准。它提供 VR ready 输出讯号，并具备完整的故障保护功能，包括过电压（OV）、过电流（OC）、欠电压（UV）及欠电压锁定（UVLO）。RT3635BT 采用 WQFN-60L 7x7 footprint 封装。建议操作接面温度范围为 −40°C 至 125°C。
RT3635BT 电路图
anchor
productDetailSection
i18n(anchor-tab.product-detail-section.title)
productDetailSectionAnchorTab
orderingInformationSection
i18n(anchor-tab.ordering-information-section.title)
orderingInformationSectionAnchorTab
technicalDocumentationSection
i18n(anchor-tab.technical-documentation-section.title)
technicalDocumentationSectionAnchorTab
designToolSection
i18n(anchor-tab.design-tool-section.title)
designToolSectionAnchorTab
applicationSection
i18n(anchor-tab.application-section.title)
applicationSectionAnchorTab
supportSection
i18n(anchor-tab.support-section.title)
supportSectionAnchorTab
24
24
24
24
i18n(tabs.product-detail.title)
productDetailTabs
i18n(tab-item.parameter-section.title)
parameterSection
parameterSectionTab
i18n(tab-item.package-size-pin-size-section.title)
packageSizePinsSizeSection
packageSizePinsSizeSectionTab
i18n(tab-item.product-feature-section.title)
productFeatureSection
productFeatureSectionTab
24
24
24
24
buttonSeeProductDifferences
text-with-icon
right
secondary-m
tertiary
i18n(button-item.see-product-differences.button-label)
i18n(button-item.see-product-differences.button-link)
_self
false
buttonFindOtherCategory
text-with-icon
right
secondary-m
tertiary
i18n(button-item.find-other-category.button-label)
i18n(button-item.find-other-category.button-link)
_self
false
32
32
32
32
scrollable-table
parameterTable
normal-table
table-group
package-size-pins-size
packageSizePinsSizeTable
productFeature
<div class="spec-list"><ul class="lv1"><li>Intel IMVP9.2 Compliant </li><li>Configurable 5/4/3/2/1/0 Phase (VCCCORE VR) + 2/1/0 Phase (VCCGT VR) + 1/0 Phase (VCCSA VR) PWM Controller </li><li>Support Baby Phase (Heterogeneous Phase) </li><li>Support Multi-Source Dr.MOS </li><li>Support Phase Doubler RT9637 for CORE Rail Up to 10-Phase Operation </li><li>Support Application of SPS with Current Sensing by Either Current Type or Voltage Type </li><li>Easy-Set G-NAVP<sup>TM</sup> (Green Native Adaptive Voltage Positioning) Control </li><li>0.5% DAC Accuracy </li><li>Differential Remote Voltage Sensing </li><li>Internal Non-Volatile Memory (NVM) to Store Custom Configuration </li><li>Accurate Current Balance </li><li>Diode Emulation Mode at Light Load Condition </li><li>Fast Transient Response with Adaptive Quick Response (AQR) </li><li>VR Ready Indicator </li><li>Output Current Monitor </li><li>Protection Flags for OVP, OCP, and UVP </li><li>Support Fast V-Mode (FVM) </li><li>Switching Frequency Setting </li><li>Support Ton Extension in DEM </li><li>Support Current Balance in Each Phase </li><li>Slew Rate Setting </li><li>DVID Enhancement </li><li>Audio Noise Suppression Function </li><li>Smart Phase Management (SPM) Adjustment </li><li>Zero Load-Line </li><li>Standard I<sup>2</sup>C Protocol Interface - Thermal Balance Adjustment </li></ul></div>
24
24
24
24
i18n(tabs.ordering-information.title)
orderingInformationTabs
i18n(tab-item.product-section.title)
productSection
productSectionTab
i18n(tab-item.evb-section.title)
evbSection
evbSectionTab
i18n(tab-item.ordering-detail-section.title)
orderingDetailSection
orderingDetailSectionTab
24
24
24
24
productImageSwitcher
RT3635BT 订购信息
normal-table
card-list
products
productTable
evbImageSwitcher
normal-table
card-list
evb
evbTable
orderingDetail
technical-documents
RT3635BT
technicalDocumentMultipleTable
design-tools
RT3635BT
designToolMultipleTable
32
56
56
56
rt-blue-800
i18n(text.application-title.text-content)
applicationTitle
withLine
24
24
24
24
<div class="spec-list"><ul class="lv1"><li>IMVP9.2 Intel Core Supply </li><li>Notebook/Desktop Computers </li><li>AVP Step-Down Converter </li></ul></div>
