RT3645BE 是一款具备四组输出电压轨的同步 VR 控制器，并完全符合 Intel IMVP9.3 PWM 规范。RT3645BE 采用 Richtek’s 新一代混合控制架构。此混合控制可在不使用外部被动元件进行回路补偿的情况下，达到快速动态反应。控制回路设定可透过 I<sup>2</sup>C 介面轻松编程，简化 droop 控制设定流程，以满足 CPU 核心电源的所有 AVP（Adaptive Voltage Positioning）要求。RT3645BE 具备 Richtek’s 新一代暂态技术 AQR（Adaptive Quick Response），可在负载暂态期间优化 AVP 效能并减少输出电容。RT3645BE 控制器采用 SPM（Smart Phase Management）技术，并具备可编程电流阈值与迟滞，以优化系统效率。RT3645BE 整合高精度 ADC，可用于多种信号遥测，包括输入电压、输出电流、各电压轨的温度感测及系统功率监测。RT3645BE 内建 MTP NVM（Multiple-Time Programmable Non-Volatile Memory），用于储存自订配置，例如 droop 控制设定、ICCMAX 电流、切换频率及 SPM 电流阈值。这些配置可透过在 ADDR 脚位与 GND 之间放置指定电阻来选择。RT3645BE 亦支援故障保护，包括欠电压锁定（UVLO）、欠电压（UV）、过电压（OV）、过电流（OC）及 SPS 故障指示。建议接面温度范围为 −40°C 至 125°C。
RT3645BE 电路图
width
fixed-width
id
basicInfoImageSection
anchor
productDetailSection
i18n(anchor-tab.product-detail-section.title)
productDetailSectionAnchorTab
orderingInformationSection
i18n(anchor-tab.ordering-information-section.title)
orderingInformationSectionAnchorTab
technicalDocumentationSection
i18n(anchor-tab.technical-documentation-section.title)
technicalDocumentationSectionAnchorTab
designToolSection
i18n(anchor-tab.design-tool-section.title)
designToolSectionAnchorTab
applicationSection
i18n(anchor-tab.application-section.title)
applicationSectionAnchorTab
supportSection
i18n(anchor-tab.support-section.title)
supportSectionAnchorTab
width
full-width
id
anchorSection
24
24
24
24
i18n(tabs.product-detail.title)
productDetailTabs
i18n(tab-item.parameter-section.title)
parameterSection
parameterSectionTab
i18n(tab-item.package-size-pin-size-section.title)
packageSizePinsSizeSection
packageSizePinsSizeSectionTab
i18n(tab-item.product-feature-section.title)
productFeatureSection
productFeatureSectionTab
24
24
24
24
buttonSeeProductDifferences
text-with-icon
right
secondary-m
tertiary
i18n(button-item.see-product-differences.button-label)
i18n(button-item.see-product-differences.button-link)
_self
false
buttonFindOtherCategory
text-with-icon
right
secondary-m
tertiary
i18n(button-item.find-other-category.button-label)
i18n(button-item.find-other-category.button-link)
_self
false
32
32
32
32
width
fixed-width
backgroundColor
F5F6F8
id
productDetailSection
scrollable-table
parameterTable
width
fixed-width
id
parameterSection
normal-table
table-group
package-size-pins-size
packageSizePinsSizeTable
width
fixed-width
id
packageSizePinsSizeSection
productFeature
<div class="spec-list"><ul class="lv1"><li>Compliant with Intel IMVP9.3 Specification </li><li>5/4/3/2/1 Phases (CORE VR) + 2/1 Phases (GT VR) + 1 Phase (SA VR) + 1 Phase (ATOM VR) </li><li>Hybrid Control Architecture without External RC Components </li><li>Good Stability and Fast Dynamic Performance: Adaptive Ramp and Quick Response </li><li>0.5% DAC Accuracy </li><li>Differential Remote Voltage Sensing </li><li>Built-In ADC for Signal Monitoring and Telemetry </li><li>DVID Enhancement </li><li>Zero Load-Line </li><li>Smart Phase Control for Efficiency Optimization </li><li>Support Fast V-Mode (FVM) </li><li>VR Ready and Thermal Indicator </li><li>Soldering Good Detection </li><li>Standard I<sup>2</sup>C Protocol Interface <ul class="lv2"> <li></li><li>Flexible Address Options </li><li>Built-In Multiple-Time Programmable Non-Volatile Memory to Store Custom Configurations </li><li>Current Balance Control for Thermal Balance </li><li>Easy Internal Hybrid Control Loop Setting </li><li>Switching Frequency Setting </li><li>Fault Status and Protection Flags </li></ul> </li></ul></div>
width
fixed-width
id
productFeatureSection
24
24
24
24
i18n(tabs.ordering-information.title)
orderingInformationTabs
i18n(tab-item.product-section.title)
productSection
productSectionTab
i18n(tab-item.evb-section.title)
evbSection
evbSectionTab
i18n(tab-item.ordering-detail-section.title)
orderingDetailSection
orderingDetailSectionTab
24
24
24
24
width
fixed-width
id
orderingInformationSection
productImageSwitcher
RT3645BE 订购信息
normal-table
card-list
products
productTable
width
fixed-width
id
productSection
evbImageSwitcher
normal-table
card-list
evb
evbTable
width
fixed-width
id
evbSection
orderingDetail
width
fixed-width
id
orderingDetailSection
technical-documents
RT3645BE
technicalDocumentMultipleTable
width
fixed-width
id
technicalDocumentationSection
design-tools
RT3645BE
designToolMultipleTable
width
fixed-width
id
designToolSection
32
56
56
56
rt-blue-800
i18n(text.application-title.text-content)
applicationTitle
withLine
24
24
24
24
<div class="spec-list"><ul class="lv1"><li>Intel IMVP9.3 CPU Core Power </li><li>Notebook and Desktop Computers </li><li>AVP Buck Converters </li></ul></div>
