RT4527A 是一款高效率白光 LED 驱动器，适用于单节或双节电池供电系统，可驱动由六组并联 LED 串所组成的背光模组，每串最多可支援 10 颗白光 LED（WLED）。内建电流汲入器（Current Sink）可提供最高 ±2% 的通道间电流误差，确保各 LED 串之间具有优异的亮度一致性。 为了提供电流汲入器足够的工作余裕（Headroom），升压控制器会监测各回授脚位中的最低电压，并自动调整至最佳输出电压，以提升整体电源转换效率。 RT4527A 内建 I²C 介面，可用于控制调光模式、开关频率及 LED 驱动电流。产品整合 250mΩ、耐压 36V 的功率开关，并采用电流模式控制架构，提供过电流保护功能。 RT4527A 的开关频率可于 100kHz 至 1.6MHz 范围内调整，让设计人员可依效率需求与外部元件尺寸之间进行最佳化取舍。 RT4527A 采用 WQFN-20L 3.5mm × 3.5mm 封装。建议接面温度范围为 -40°C 至 125°C，环境温度范围为 -40°C 至 85°C。
RT4527A 电路图
