<div class="spec-list"><ul class="lv1"><li>Input Supply Voltage Range : 2.8V to 5.5V </li><li>Three High-Efficiency Configurable Low-Voltage Buck Converters at Default Switching Frequency of 2MHz <ul class="lv2"> <li></li><li>CH1 for ASIC Core Power : Output Current : 4A Output Voltages Programmable by REFIN Pin or 0.7V to 1.3V in 10mV/Step Via I²C </li><li>CH2 for DDR Power : Output Current : 2A Output Voltages Programmable by FB2 Pin </li><li>CH3 for Flash I/O Power : Output Current : 2A Output Voltages Programmable by FB3 Pin </li></ul> </li><li>One LDO of Low Quiescent Current <ul class="lv2"> <li></li><li>LDO for Analog and PHY Power : Output Current : 300mA Output Voltages Programmable by FB4 Pin </li></ul> </li><li>Gate Control for External N-MOSFET Against Inrush Current from Power Input </li><li>Internal Soft-Start and Current Limit Protection for CH1 to CH3 and LDO </li><li><span style="text-decoration: overline">STANDBY</span> Pin for Sleep Mode Control </li><li>Two Output Pins to Control External Regulators/ Switches </li><li>One Input Pin to Sense External Regulators/ Switches Output Voltage </li><li>High-Speed Mode I²C Interface for CH1 Output Voltage Programming </li><li>PGOOD Indicator for VSYS, CH1 to CH3, and LDO Output Voltages Monitoring </li><li>RST_L Indicator for Reset Condition of VSYS </li><li>Power-On Sequence Control During Start-up </li><li>Over-Voltage Protection (OVP), Under-Voltage Protection (UVP), Under-Voltage Lockout (UVLO), and Thermal Shutdown Protection </li><li>Small 32-Lead WQFN Package </li></ul></div>
