RT5133B 是一款电源管理 IC，专为相机感测器应用设计，内含 8 组 LDO，包括 2 路 DVDD、4 路 AVDD、1 路 VIO、1 路 VAF，以及 3 个适用于可携式装置的 GPO。各稳压器的输出电压、软启动时间及保护功能皆可透过 I²C 介面写入暂存器进行控制。LDO1 可用于提供 IO（VIO）电源；LDO2 可用于提供自动对焦模组（VAF）电源；LDO3 至 LDO6 可用于提供 AVDD 电源；LDO7 与 LDO8 可用于提供 DVDD 电源。3 个 GPO 输出脚位可控制外部装置，或重新配置为其他用途。RT5133B 采用 WL-CSP1.84x1.84-25(BSC) 封装。建议接面温度范围为 -40°C 至 125°C，环境温度范围为 -40°C 至 85°C。
RT5133B 电路图
width
fixed-width
id
basicInfoImageSection
anchor
productDetailSection
i18n(anchor-tab.product-detail-section.title)
productDetailSectionAnchorTab
orderingInformationSection
i18n(anchor-tab.ordering-information-section.title)
orderingInformationSectionAnchorTab
technicalDocumentationSection
i18n(anchor-tab.technical-documentation-section.title)
technicalDocumentationSectionAnchorTab
designToolSection
i18n(anchor-tab.design-tool-section.title)
designToolSectionAnchorTab
applicationSection
i18n(anchor-tab.application-section.title)
applicationSectionAnchorTab
supportSection
i18n(anchor-tab.support-section.title)
supportSectionAnchorTab
width
full-width
id
anchorSection
24
24
24
24
i18n(tabs.product-detail.title)
productDetailTabs
i18n(tab-item.parameter-section.title)
parameterSection
parameterSectionTab
i18n(tab-item.package-size-pin-size-section.title)
packageSizePinsSizeSection
packageSizePinsSizeSectionTab
i18n(tab-item.product-feature-section.title)
productFeatureSection
productFeatureSectionTab
24
24
24
24
buttonSeeProductDifferences
text-with-icon
right
secondary-m
tertiary
i18n(button-item.see-product-differences.button-label)
i18n(button-item.see-product-differences.button-link)
_self
false
buttonFindOtherCategory
text-with-icon
right
secondary-m
tertiary
i18n(button-item.find-other-category.button-label)
i18n(button-item.find-other-category.button-link)
_self
false
32
32
32
32
width
fixed-width
backgroundColor
F5F6F8
id
productDetailSection
scrollable-table
parameterTable
width
fixed-width
id
parameterSection
normal-table
table-group
package-size-pins-size
packageSizePinsSizeTable
width
fixed-width
id
packageSizePinsSizeSection
productFeature
<div class="spec-list"><ul class="lv1"><li>Top - Hardware Enable Pin - I<sup>2</sup>C Controlled Interface - Programmable Channel Power-On/Off - IRQB Output for Indication - Input Undervoltage Protection - Over-Temperature Protection </li><li>LDO - LDO1/2 - Two Low Dropout Regulators for V1018 and Auto Focus Applications - Wide 2.8V to 5V Operating Input Range - Programmable Output Voltage by I<sup>2</sup>C - High PSRR: 70dB @ 1KHz - 300mA Low Dropout Voltage Regulators - LDO3/4/5/6 - Four Low Dropout Regulators for AVDD Applications - Wide 2.8V to 5V Operating Input Range - Programmable Output Voltage by I2C - High PSRR: 85dB @ 1KHz - 300mA Low Dropout Voltage Regulators - LDO7/8 - 2 Low Dropout Regulators for AVDD Applications - Wide 1.1V to 5V Operating Input Range - Programmable Output Voltage by I2C - High PSRR: 75dB @ 1KHz - 600mA/1000mA Low Dropout Voltage Regulators </li><li>GPO - Three GPO Pins to Control a Single Regulator </li></ul></div>
width
fixed-width
id
productFeatureSection
24
24
24
24
i18n(tabs.ordering-information.title)
orderingInformationTabs
i18n(tab-item.product-section.title)
productSection
productSectionTab
i18n(tab-item.evb-section.title)
evbSection
evbSectionTab
i18n(tab-item.ordering-detail-section.title)
orderingDetailSection
orderingDetailSectionTab
24
24
24
24
width
fixed-width
id
orderingInformationSection
productImageSwitcher
RT5133B 订购信息
normal-table
card-list
products
productTable
width
fixed-width
id
productSection
evbImageSwitcher
normal-table
card-list
evb
evbTable
width
fixed-width
id
evbSection
orderingDetail
width
fixed-width
id
orderingDetailSection
technical-documents
RT5133B
technicalDocumentMultipleTable
width
fixed-width
id
technicalDocumentationSection
design-tools
RT5133B
designToolMultipleTable
width
fixed-width
id
designToolSection
32
56
56
56
rt-blue-800
i18n(text.application-title.text-content)
applicationTitle
withLine
24
24
24
24
<div class="spec-list"><ul class="lv1"><li>Cellular Telephones </li><li>Personal Information Appliances </li><li>Tablet PCs </li><li>Portable Instruments </li></ul></div>
