RT7056 是专门针对先进电机驱动应用的 sIPM<SUP>™</SUP> 系列产品之一，它内含 PMSM/BLDC 电机控制器、线性稳压器、栅极驱动器、自举二极体和 IGBT 元件，是针对 PMSM/BLDC 电机应用进行了优化的专用产品，可为使用者带来最优的性价比，具有设计简单、节省空间、可靠性高等特性。<BR>RT7056 的封装形式为 SOP-23。建议的接面温度范围为-40°C至125°C，而环境温度范围则为-40°C至105°C。
RT7056 电路图
