RTQ1950/RTQ1950A 可为 10V 至 80V 系统提供企业级保护与高效能监控功能，特别适用于 48V/54V 资料中心网路设备等应用。产品具备低于毫秒等级的短路故障响应时间、高解析度可程式化电流限制设定，以及远端温度感测功能，并支援可调式警告与关机温度门槛，以保护及监控关键系统。 RTQ1950/RTQ1950A 内建可程式化 MOSFET 安全操作区域（SOA）保护功能，可精确控制 MOSFET 的最大功率耗散；同时具备 MOSFET 健康状态警告与侦测演算法，即使 MOSFET 处于完全导通状态，仍可持续监控其运作状况。可调式故障计时器（Fault Timer）则可避免误触发，并限制过载事件持续时间。 在监控功能方面，RTQ1950/RTQ1950A 可即时量测功率、电压、电流、温度及故障资讯，并透过 I²C/SMBus 介面，以符合 PMBus 指令架构的方式传送相关资讯。高精度遥测（Telemetry）功能可支援智慧电源管理应用，例如 Intel PROCHOT 输出、电源最佳化以及早期故障侦测。 此外，RTQ1950/RTQ1950A 提供可调式遥测平均功能（Telemetry Averaging）与峰值功率量测功能，可进一步提升系统诊断能力。 RTQ1950/RTQ1950A 与市场上同类型产品脚位完全相容（TSSOP-28 Exposed Pad 封装），同时提供多项性能与功能上的改进优势。 建议接面温度范围为 -40°C 至 125°C。
RTQ1950/RTQ1950A 电路图
anchor
productDetailSection
i18n(anchor-tab.product-detail-section.title)
productDetailSectionAnchorTab
orderingInformationSection
i18n(anchor-tab.ordering-information-section.title)
orderingInformationSectionAnchorTab
technicalDocumentationSection
i18n(anchor-tab.technical-documentation-section.title)
technicalDocumentationSectionAnchorTab
designToolSection
i18n(anchor-tab.design-tool-section.title)
designToolSectionAnchorTab
applicationSection
i18n(anchor-tab.application-section.title)
applicationSectionAnchorTab
supportSection
i18n(anchor-tab.support-section.title)
supportSectionAnchorTab
24
24
24
24
i18n(tabs.product-detail.title)
productDetailTabs
i18n(tab-item.parameter-section.title)
parameterSection
parameterSectionTab
i18n(tab-item.package-size-pin-size-section.title)
packageSizePinsSizeSection
packageSizePinsSizeSectionTab
i18n(tab-item.product-feature-section.title)
productFeatureSection
productFeatureSectionTab
24
24
24
24
buttonSeeProductDifferences
text-with-icon
right
secondary-m
tertiary
i18n(button-item.see-product-differences.button-label)
i18n(button-item.see-product-differences.button-link)
_self
false
buttonFindOtherCategory
text-with-icon
right
secondary-m
tertiary
i18n(button-item.find-other-category.button-label)
i18n(button-item.find-other-category.button-link)
_self
false
32
32
32
32
scrollable-table
parameterTable
normal-table
table-group
package-size-pins-size
packageSizePinsSizeTable
productFeature
<div class="spec-list"><ul class="lv1"><li>VIN: 10V to 80V (100V AMR) </li><li>VIN to VIN_K: ±60V AMR </li><li>OUT: -5V to 100V AMR </li><li>12-Bit 1 kHz ADC Telemetry (-40°C to 125°C) - ±0.8% Voltage Accuracy - ±1% Current Accuracy - ±1.8% Power Accuracy (Energy Monitoring Supported) </li><li>10 to 55mV Current Limit Sense Voltage in 1mV Increments </li><li>Programmable MOSFET SOA Protection - Fast 500ns Response to Short-Circuit - Accurate Control - MOSFET Health Warning/Detection - Remote Temperature Sensing with Adjustable Warning/Shutdown Thresholds - PROCHOT Output (VAUX) - Programable UV, OV Thresholds - PMBus Compliant Command Structure - -40°C < TJ < 125°C Operation - Available in TSSOP-28 9.7×4.4 mm<sup>2</sup> </li></ul></div>
24
24
24
24
i18n(tabs.ordering-information.title)
orderingInformationTabs
i18n(tab-item.product-section.title)
productSection
productSectionTab
i18n(tab-item.evb-section.title)
evbSection
evbSectionTab
i18n(tab-item.ordering-detail-section.title)
orderingDetailSection
orderingDetailSectionTab
24
24
24
24
productImageSwitcher
RTQ1950/RTQ1950A 订购信息
normal-table
card-list
products
productTable
evbImageSwitcher
normal-table
card-list
evb
evbTable
orderingDetail
technical-documents
RTQ1950/RTQ1950A
technicalDocumentMultipleTable
design-tools
RTQ1950/RTQ1950A
designToolMultipleTable
32
56
56
56
rt-blue-800
i18n(text.application-title.text-content)
applicationTitle
withLine
24
24
24
24
<div class="spec-list"><ul class="lv1"><li>48V/54V Servers and Network Equipment </li><li>Datacenter Rack Power Distribution </li><li>Base Station Power Distribution </li><li>PLC Power Management </li><li>Industrial Systems </li></ul></div>
