RT5133B 是一款電源管理 IC，專為相機感測器應用設計，內含 8 組 LDO，包括 2 路 DVDD、4 路 AVDD、1 路 VIO、1 路 VAF，以及 3 個適用於可攜式裝置的 GPO。各穩壓器的輸出電壓、軟啟動時間及保護功能皆可透過 I²C 介面寫入暫存器進行控制。LDO1 可用於提供 IO（VIO）電源；LDO2 可用於提供自動對焦模組（VAF）電源；LDO3 至 LDO6 可用於提供 AVDD 電源；LDO7 與 LDO8 可用於提供 DVDD 電源。3 個 GPO 輸出腳位可控制外部裝置，或重新配置為其他用途。RT5133B 採用 WL-CSP1.84x1.84-25(BSC) 封裝。建議接面溫度範圍為 -40°C 至 125°C，環境溫度範圍為 -40°C 至 85°C。
RT5133B 電路圖
anchor
productDetailSection
i18n(anchor-tab.product-detail-section.title)
productDetailSectionAnchorTab
orderingInformationSection
i18n(anchor-tab.ordering-information-section.title)
orderingInformationSectionAnchorTab
technicalDocumentationSection
i18n(anchor-tab.technical-documentation-section.title)
technicalDocumentationSectionAnchorTab
designToolSection
i18n(anchor-tab.design-tool-section.title)
designToolSectionAnchorTab
applicationSection
i18n(anchor-tab.application-section.title)
applicationSectionAnchorTab
supportSection
i18n(anchor-tab.support-section.title)
supportSectionAnchorTab
24
24
24
24
i18n(tabs.product-detail.title)
productDetailTabs
i18n(tab-item.parameter-section.title)
parameterSection
parameterSectionTab
i18n(tab-item.package-size-pin-size-section.title)
packageSizePinsSizeSection
packageSizePinsSizeSectionTab
i18n(tab-item.product-feature-section.title)
productFeatureSection
productFeatureSectionTab
24
24
24
24
buttonSeeProductDifferences
text-with-icon
right
secondary-m
tertiary
i18n(button-item.see-product-differences.button-label)
i18n(button-item.see-product-differences.button-link)
_self
false
buttonFindOtherCategory
text-with-icon
right
secondary-m
tertiary
i18n(button-item.find-other-category.button-label)
i18n(button-item.find-other-category.button-link)
_self
false
32
32
32
32
scrollable-table
parameterTable
normal-table
table-group
package-size-pins-size
packageSizePinsSizeTable
productFeature
<div class="spec-list"><ul class="lv1"><li>Top - Hardware Enable Pin - I<sup>2</sup>C Controlled Interface - Programmable Channel Power-On/Off - IRQB Output for Indication - Input Undervoltage Protection - Over-Temperature Protection </li><li>LDO - LDO1/2 - Two Low Dropout Regulators for V1018 and Auto Focus Applications - Wide 2.8V to 5V Operating Input Range - Programmable Output Voltage by I<sup>2</sup>C - High PSRR: 70dB @ 1KHz - 300mA Low Dropout Voltage Regulators - LDO3/4/5/6 - Four Low Dropout Regulators for AVDD Applications - Wide 2.8V to 5V Operating Input Range - Programmable Output Voltage by I2C - High PSRR: 85dB @ 1KHz - 300mA Low Dropout Voltage Regulators - LDO7/8 - 2 Low Dropout Regulators for AVDD Applications - Wide 1.1V to 5V Operating Input Range - Programmable Output Voltage by I2C - High PSRR: 75dB @ 1KHz - 600mA/1000mA Low Dropout Voltage Regulators </li><li>GPO - Three GPO Pins to Control a Single Regulator </li></ul></div>
24
24
24
24
i18n(tabs.ordering-information.title)
orderingInformationTabs
i18n(tab-item.product-section.title)
productSection
productSectionTab
i18n(tab-item.evb-section.title)
evbSection
evbSectionTab
i18n(tab-item.ordering-detail-section.title)
orderingDetailSection
orderingDetailSectionTab
24
24
24
24
productImageSwitcher
RT5133B 訂購資訊
normal-table
card-list
products
productTable
evbImageSwitcher
normal-table
card-list
evb
evbTable
orderingDetail
technical-documents
RT5133B
technicalDocumentMultipleTable
design-tools
RT5133B
designToolMultipleTable
32
56
56
56
rt-blue-800
i18n(text.application-title.text-content)
applicationTitle
withLine
24
24
24
24
<div class="spec-list"><ul class="lv1"><li>Cellular Telephones </li><li>Personal Information Appliances </li><li>Tablet PCs </li><li>Portable Instruments </li></ul></div>
