RT7056 是專門針對先進電機驅動應用的 sIPM<SUP>™</SUP> 系列產品之一，它內含 PMSM/BLDC 電機控制器、線性穩壓器、柵極驅動器、自舉二極體和 IGBT 元件，是針對 PMSM/BLDC 電機應用進行了優化的專用產品，可為使用者帶來最優的性價比，具有設計簡單、節省空間、可靠性高等特性。<BR>RT7056 的封裝形式為 SOP-23。建議的接面溫度範圍為-40°C至125°C，而環境溫度範圍則為-40°C至105°C。
RT7056 電路圖
