RT7084C2M 是一款專為 PMSM（永磁同步馬達）及 BLDC（無刷直流馬達）應用所設計的專用積體電路（ASIC）。此二合一 ASIC 整合多項功能電路，包括三相馬達控制器、三相閘極驅動器、三個自舉二極體、5V LDO，以及降壓轉換器（Buck Converter）。 RT7084C2M 內建 ARM 32 位元 Cortex-M0 核心及周邊電路，可實現無感測器磁場導向控制（Sensorless FOC）。此外，此 ASIC 提供多項系統級周邊功能，包括 ADC 輸入濾波器、通訊介面、溫度感測器、短路保護（SCP）及堵轉保護功能，以減少元件數量、縮小 PCB 面積並降低系統成本。 此外，RT7084C2M 可驅動外接 N 通道 MOSFET，形成三組半橋架構，並內建自舉電路。 RT7084C2M 採用 VQFN-32L（4mm × 4mm）封裝。建議接面溫度範圍為 -40°C 至 125°C，環境溫度範圍為 -40°C 至 105°C。
RT7084C2M 電路圖
width
fixed-width
id
basicInfoImageSection
anchor
productDetailSection
i18n(anchor-tab.product-detail-section.title)
productDetailSectionAnchorTab
orderingInformationSection
i18n(anchor-tab.ordering-information-section.title)
orderingInformationSectionAnchorTab
technicalDocumentationSection
i18n(anchor-tab.technical-documentation-section.title)
technicalDocumentationSectionAnchorTab
designToolSection
i18n(anchor-tab.design-tool-section.title)
designToolSectionAnchorTab
applicationSection
i18n(anchor-tab.application-section.title)
applicationSectionAnchorTab
supportSection
i18n(anchor-tab.support-section.title)
supportSectionAnchorTab
width
full-width
id
anchorSection
24
24
24
24
i18n(tabs.product-detail.title)
productDetailTabs
i18n(tab-item.parameter-section.title)
parameterSection
parameterSectionTab
i18n(tab-item.package-size-pin-size-section.title)
packageSizePinsSizeSection
packageSizePinsSizeSectionTab
i18n(tab-item.product-feature-section.title)
productFeatureSection
productFeatureSectionTab
24
24
24
24
buttonSeeProductDifferences
text-with-icon
right
secondary-m
tertiary
i18n(button-item.see-product-differences.button-label)
i18n(button-item.see-product-differences.button-link)
_self
false
buttonFindOtherCategory
text-with-icon
right
secondary-m
tertiary
i18n(button-item.find-other-category.button-label)
i18n(button-item.find-other-category.button-link)
_self
false
32
32
32
32
width
fixed-width
backgroundColor
F5F6F8
id
productDetailSection
scrollable-table
parameterTable
width
fixed-width
id
parameterSection
normal-table
table-group
package-size-pins-size
packageSizePinsSizeTable
width
fixed-width
id
packageSizePinsSizeSection
productFeature
<div class="spec-list"><ul class="lv1"><li>Integrates 3-Phase PMSM/BLDC Controller, Gate Driver, Bootstrap Diodes, 5V LDO, and Gate Driver LDO </li><li>Input Voltage Range: 16V to 80V </li><li>Sensorless, Sine-Wave Field Oriented Control (FOC) </li><li>Integrates Filters at ADC Input </li><li>Protections: SCP, UVLO, Locked-Rotor, and Thermal Detection </li><li>PMSM/BLDC Motor Controller- ARM 32-bit Cortex-M0 CPU, Frequency up to 60MHz- Memories Size: 16kB MTP, Internal ROM with Embedded Motor Control Library and 4kB SRAM- Power Management: Deep Sleep- Communication Interface: I<sup>2</sup>C and UART- Configurable ADC Gain: x1, x4, and x8- 5-Channel 12-Bit ADC- AD0 to AD3 for Differential Mode Current Sense- AD6 to AD8 for System Application - 1-Channel Voltage Type 8-bit DAC </li><li>Gate Driver- Floating Channel Designed for Bootstrap Operation- Sourcing/Sinking Current: 100mA/200mA- Built-In UVLO Functions for All Channels- Matched Propagation Delays for All Channels </li><li>VQFN-32L 4x4 Package </li></ul></div>
width
fixed-width
id
productFeatureSection
24
24
24
24
i18n(tabs.ordering-information.title)
orderingInformationTabs
i18n(tab-item.product-section.title)
productSection
productSectionTab
i18n(tab-item.evb-section.title)
evbSection
evbSectionTab
i18n(tab-item.ordering-detail-section.title)
orderingDetailSection
orderingDetailSectionTab
24
24
24
24
width
fixed-width
id
orderingInformationSection
productImageSwitcher
RT7084C2M 訂購資訊
normal-table
card-list
products
productTable
width
fixed-width
id
productSection
evbImageSwitcher
normal-table
card-list
evb
evbTable
width
fixed-width
id
evbSection
orderingDetail
width
fixed-width
id
orderingDetailSection
technical-documents
RT7084C2M
technicalDocumentMultipleTable
width
fixed-width
id
technicalDocumentationSection
design-tools
RT7084C2M
designToolMultipleTable
width
fixed-width
id
designToolSection
32
56
56
56
rt-blue-800
i18n(text.application-title.text-content)
applicationTitle
withLine
24
24
24
24
<div class="spec-list"><ul class="lv1"><li>Server Fan </li><li>Telecom Fan </li><li>Liquid Pump </li></ul></div>
