RTQ2812B 是一款同步降壓轉換器，可在 3.5V 至 17V 的寬輸入電壓範圍內提供最高 12A 輸出電流。裝置整合低 RDS(ON) 功率 MOSFET、全工作接面溫度範圍內精度達 0.6V ±1% 的參考電壓，以及用於自舉電路的內建二極體，提供高度精簡的解決方案。RTQ2812B 採用 Advanced Constant-On-Time（ACOT®）控制架構，可提供優異的瞬態響應能力並減少外部元件數量。在穩態運作下，ACOT® 技術能在不同輸入電壓、負載及輸出電壓條件下維持接近固定的切換頻率，使 EMI 濾波器設計更為容易。此元件提供多項功能以提升設計彈性，包括可選擇的切換頻率、電流限制等級及 PWM 操作模式，使 RTQ2812B 能輕鬆應用於各類設計。另提供獨立啟用控制輸入與 Power-Good 指示訊號，以簡化電源時序控制。透過接於 SS 腳位的外部電容，可設定可程式化軟啟動時間，以控制啟動期間的湧入電流。RTQ2812B 具備完整保護機制，包括輸入欠壓鎖定（UVLO）、輸出欠壓保護（UVP）、輸出過壓保護（OVP）、過電流保護（OCP）及過溫保護（OTP）。RTQ2812B 採用強化散熱 WQFN3x4-21T(FC) 封裝，建議接面溫度範圍為 -40°C 至 150°C。
RTQ2812B 電路圖
width
fixed-width
id
basicInfoImageSection
anchor
productDetailSection
i18n(anchor-tab.product-detail-section.title)
productDetailSectionAnchorTab
orderingInformationSection
i18n(anchor-tab.ordering-information-section.title)
orderingInformationSectionAnchorTab
technicalDocumentationSection
i18n(anchor-tab.technical-documentation-section.title)
technicalDocumentationSectionAnchorTab
designToolSection
i18n(anchor-tab.design-tool-section.title)
designToolSectionAnchorTab
applicationSection
i18n(anchor-tab.application-section.title)
applicationSectionAnchorTab
supportSection
i18n(anchor-tab.support-section.title)
supportSectionAnchorTab
width
full-width
id
anchorSection
24
24
24
24
i18n(tabs.product-detail.title)
productDetailTabs
i18n(tab-item.parameter-section.title)
parameterSection
parameterSectionTab
i18n(tab-item.package-size-pin-size-section.title)
packageSizePinsSizeSection
packageSizePinsSizeSectionTab
i18n(tab-item.product-feature-section.title)
productFeatureSection
productFeatureSectionTab
24
24
24
24
buttonSeeProductDifferences
text-with-icon
right
secondary-m
tertiary
i18n(button-item.see-product-differences.button-label)
i18n(button-item.see-product-differences.button-link)
_self
false
buttonFindOtherCategory
text-with-icon
right
secondary-m
tertiary
i18n(button-item.find-other-category.button-label)
i18n(button-item.find-other-category.button-link)
_self
false
32
32
32
32
width
fixed-width
backgroundColor
F5F6F8
id
productDetailSection
scrollable-table
parameterTable
width
fixed-width
id
parameterSection
normal-table
table-group
package-size-pins-size
packageSizePinsSizeTable
width
fixed-width
id
packageSizePinsSizeSection
productFeature
<div class="spec-list"><ul class="lv1"><li>Wide Input Voltage Range <ul class="lv2"> <li></li><li>2.7V to 17V with External 3.3V VCC Bias </li><li>3.5V to 17V with Internal VCC Bias </li></ul> </li><li>Output Voltage from 0.6V to 5.5V </li><li>0.6V ± 0.5% Voltage Reference from 0°C to 70°C Junction Temperature Range </li><li>0.6V ± 1% Voltage Reference from -40°C to 150°C Junction Temperature Range </li><li>ACOT<sup>®</sup> Control for Excellent Transient Performance </li><li>Stable with Ceramic Output Capacitors </li><li>Selectable FCCM or PSM Operation at Light Load </li><li>Selectable Operation Switching Frequency (600KHz/800KHz/1MHz) </li><li>Non-Latch for OCP, UVP, UVLO, and OTP Faults. Latch-Off for OVP </li><li>Differential Remote Sense Voltage for High Output Accuracy </li><li>Power-Good Indicator </li><li>Enable Control </li><li>Programmable Soft-Start Time with a Default of 1ms </li><li>Programmable Valley Current Limit Level </li><li>Monotonic Start-Up into Pre-Biased Outputs </li><li>Small 21T-Lead WQFN (3x4) (FC) Package </li></ul></div>
