RTQ5132 是一款整合式電源管理 IC（PMIC），適用於一般 DDR5 SODIMM 與 UDIMM 應用。此元件內建三組降壓轉換器（Buck Converter，SWA、SWB 與 SWC）以及兩組 LDO 穩壓器（VLDO_1.0V 與 VLDO_1.8V），可提供 DDR5 模組所需的多組電源軌。 此外，RTQ5132 支援可選擇的通訊介面（I²C 或 I3C Basic），可因應不同應用環境及系統需求。 本產品內建完整的保護機制，以確保電源分配安全可靠。當發生異常狀況時，相關故障事件可記錄於內部暫存器中，並透過 PWR_GOOD 與 GSI_n 開漏（Open-Drain）訊號輸出進行狀態指示。 RTQ5132 採用 WQFN-28L 3mm × 4mm（FC）封裝。建議接面溫度範圍為 -10°C 至 125°C，環境溫度範圍為 0°C 至 85°C。
RTQ5132 電路圖
width
fixed-width
id
basicInfoImageSection
anchor
productDetailSection
i18n(anchor-tab.product-detail-section.title)
productDetailSectionAnchorTab
orderingInformationSection
i18n(anchor-tab.ordering-information-section.title)
orderingInformationSectionAnchorTab
technicalDocumentationSection
i18n(anchor-tab.technical-documentation-section.title)
technicalDocumentationSectionAnchorTab
designToolSection
i18n(anchor-tab.design-tool-section.title)
designToolSectionAnchorTab
applicationSection
i18n(anchor-tab.application-section.title)
applicationSectionAnchorTab
supportSection
i18n(anchor-tab.support-section.title)
supportSectionAnchorTab
width
full-width
id
anchorSection
24
24
24
24
i18n(tabs.product-detail.title)
productDetailTabs
i18n(tab-item.parameter-section.title)
parameterSection
parameterSectionTab
i18n(tab-item.package-size-pin-size-section.title)
packageSizePinsSizeSection
packageSizePinsSizeSectionTab
i18n(tab-item.product-feature-section.title)
productFeatureSection
productFeatureSectionTab
24
24
24
24
buttonSeeProductDifferences
text-with-icon
right
secondary-m
tertiary
i18n(button-item.see-product-differences.button-label)
i18n(button-item.see-product-differences.button-link)
_self
false
buttonFindOtherCategory
text-with-icon
right
secondary-m
tertiary
i18n(button-item.find-other-category.button-label)
i18n(button-item.find-other-category.button-link)
_self
false
32
32
32
32
width
fixed-width
backgroundColor
F5F6F8
id
productDetailSection
scrollable-table
parameterTable
width
fixed-width
id
parameterSection
normal-table
table-group
package-size-pins-size
packageSizePinsSizeTable
width
fixed-width
id
packageSizePinsSizeSection
productFeature
<div class="spec-list"><ul class="lv1"><li>VIN_Bulk with Input Supply Range: 4.25V to 5.5V </li><li>High Integration: - Three High Efficiency Buck Converters- SWA: I<sub>TDC</sub> = 4A, I<sub>MAX</sub> = 5A- SWB: I<sub>TDC</sub> = 4A, I<sub>MAX</sub> = 5A- SWC: I<sub>TDC</sub> = 1A, I<sub>MAX</sub> = 2A- Two LDOs - VLDO_1.8V: I<sub>MAX</sub> = 25mA- VLDO_1.0V: I<sub>MAX</sub> = 20mA </li><li>0.75% Converter Output Accuracy </li><li>Fast Transient Response with A<sup>2</sup>RCOT Control </li><li>Support I<sup>2</sup>C and I3C Slave Control </li><li>Error Log Counter and Data Storage (NVM) </li><li>MTP Registers with Secured R/W Access </li><li>Programmable and DIMM Specific Registers for Customization </li><li>Programmable Mode for Debug and Validation </li><li>Telemetry for Output Current, Voltage and Power </li><li>Complete Protection Mechanisms - VIN_Bulk Input Supply OVP - OVP, UVP, OCP, HCW for Each Rails - High Temp Warning and OTP </li><li>General Status Interrupt Function </li><li>Power-Good Indicator </li></ul></div>
