RTQ6053/RTQ6053B 是一款高精度電流感測監測器，具備 I<sup>2</sup>C 與 SMBus 介面，可透過讀取負載電流與功率提供完整系統資訊。此元件監測感測電阻兩端的壓降與 BUS 電壓，並透過內部類比數位轉換器 (ADC) 將這些量測值轉換為以安培表示的電流與以瓦特表示的功率。其整合可程式化校準、可調式轉換時間與平均功能，以提供更高的設計靈活性。RTQ6053/RTQ6053B 可在 −40°C 至 125°C 的寬溫度範圍內運作，並支援 2.7V 至 5.5V 的輸入電壓。此元件能夠在 0V 至 36V 的共模匯流排電壓下感測電流。其提供開汲極警示輸出以進行系統保護，使主機能在過電流、過壓或過功率狀況發生時接收警告。RTQ6053/RTQ6053B 採用小型 VQFN-16L 3x3 封裝。
RTQ6053/RTQ6053B 電路圖
width
fixed-width
id
basicInfoImageSection
anchor
productDetailSection
i18n(anchor-tab.product-detail-section.title)
productDetailSectionAnchorTab
orderingInformationSection
i18n(anchor-tab.ordering-information-section.title)
orderingInformationSectionAnchorTab
technicalDocumentationSection
i18n(anchor-tab.technical-documentation-section.title)
technicalDocumentationSectionAnchorTab
designToolSection
i18n(anchor-tab.design-tool-section.title)
designToolSectionAnchorTab
applicationSection
i18n(anchor-tab.application-section.title)
applicationSectionAnchorTab
supportSection
i18n(anchor-tab.support-section.title)
supportSectionAnchorTab
width
full-width
id
anchorSection
24
24
24
24
i18n(tabs.product-detail.title)
productDetailTabs
i18n(tab-item.parameter-section.title)
parameterSection
parameterSectionTab
i18n(tab-item.package-size-pin-size-section.title)
packageSizePinsSizeSection
packageSizePinsSizeSectionTab
i18n(tab-item.product-feature-section.title)
productFeatureSection
productFeatureSectionTab
24
24
24
24
buttonSeeProductDifferences
text-with-icon
right
secondary-m
tertiary
i18n(button-item.see-product-differences.button-label)
i18n(button-item.see-product-differences.button-link)
_self
false
buttonFindOtherCategory
text-with-icon
right
secondary-m
tertiary
i18n(button-item.find-other-category.button-label)
i18n(button-item.find-other-category.button-link)
_self
false
32
32
32
32
width
fixed-width
backgroundColor
F5F6F8
id
productDetailSection
scrollable-table
parameterTable
width
fixed-width
id
parameterSection
normal-table
table-group
package-size-pins-size
packageSizePinsSizeTable
width
fixed-width
id
packageSizePinsSizeSection
productFeature
<div class="spec-list"><ul class="lv1"><li>I<sup>2</sup>C and SMBus Compatible Interface </li><li>I<sup>2</sup>C Input Level: - RTQ6053: V<sub>IH</sub> = 1.2V, V<sub>IL</sub> = 0.4V - RTQ6053B: V<sub>IH</sub> = 0.7 x V<sub>S</sub>, V<sub>IL</sub>= 0.3 x VS </li><li>Bi-Direction Current Sensing, Supporting Both High-Side and Low-Side Configurations </li><li>2.7V to 5.5V Operation Supply Voltage Range </li><li>Monitor Bus Voltage from 0V to 36V </li><li>High Accuracy: Maximum 0.3% Gain Error </li><li>Low Offset Voltage: Maximum 25μV Offset </li><li>Current, Bus Voltage and System Power Reporting </li><li>Programmable Warning Threshold </li><li>Overcurrent, Overvoltage and Overpower Alert Functions </li><li>VQFN-16L 3x3 Package </li></ul></div>
