✅ Fast Transient Response – For Dynamic Load Conditions ：
In enterprise servers and high-performance computing platforms, processors and ASICs have wide dynamic load profiles within microseconds. This series adopts Richtek’s unique fast current mode control with built-in compensation, enabling the output voltage deviation to remain within 5%* during load transients from 0A to full load, outperforming other pin-compatible solutions. The fixed-frequency control also enhances EMI performance and simplifies external component count. (*Test conditions: Vin=12V, Vo=1V, fSW=2.2MHz, Io=0A→6A, SR=1A/μs)
✅ Precision Regulation – Stable Output Control：
With modern processors requiring tighter voltage tolerances and lower core voltages, this series supports output voltage as low as 0.5V and delivers excellent line/load regulation. Voltage deviation is maintained within ±0.05%* across a wide dynamic range, providing precise and stable power to core modules. (*Test conditions: Vin=5V–18V, Vo=1V, fSW=2.2MHz, Io=0A→6A)
✅ Optimized EMI – Spread Spectrum Support ：
To meet stringent EMI compliance standards, this series includes an optional spread spectrum feature that reduces peak EMI emissions by spreading switching frequency energy, thereby simplifying filter design.
✅ High Output Current in a Small Package– Compact Design ：
Delivering high efficiency and up to 8A output in a compact WQFN-14L 3mmx2.5mm package, this series is an ideal fit for space-constrained designs in servers, networking, and communication systems.
|
