30μA IQ, 250mA Low-Dropout Linear Regulator

RT9083

Update Alert Share

The RT9083 is a low-dropout (LDO) voltage regulators with enable function that operates from 1.2V to 5.5V. It provides up to 250mA of output current and offers low-power operation in miniaturized packaging.

The features of low quiescent current as low as 30μA and almost zero disable current is ideal for powering the battery equipment to a longer service life. The RT9083 is stable with the ceramic output capacitor over its wide input range from 1.2V to 5.5V and the entire range of output load current (0mA to 250mA).

Applications

  • Portable, Battery Powered Equipment
  • Ultra Low Power Microcontrollers
  • Notebook computers
  • Internet of Things
Key Spec.
RT9083 RT9083N
Status Active Active
Vin (min) (V) 1.2 1.2
Vin (max) (V) 5.5 5.5
Vout (min) (V) 0.9 0.9
Vout (max) (V) 3.3 3.3
Output Adj. Method Fixed;Resistor Fixed;Resistor
Accuracy (+/- %) 2 2
Iout (max) (mA) 250 250
Iq (typ) (uA) 30 30
Current Limit (typ) (mA)
Vdropout @ rated current (typ) (mV) 450 @ 0.25A 450 @ 0.25A
Cout (min) (uF)
Cout Type Ceramic Ceramic
Features Enable Input;High PSRR;Low Dropout;Stable with Ceramic Capacitor Enable Input;High PSRR;Low Dropout;Stable with Ceramic Capacitor
Package Type TSOT-25 TSOT-25
Features
  • 30μA Ground Current
  • PSRR = 75dB at 1kHz
  • Adjustable Output Voltage Available by Specific Application
  • ±2% Output Accuracy
  • 250mA (VIN ≥ 2.3V) Output Current with EN
  • Low (0.1μA) Disable Current
  • 1.2V to 5.5V Operating Input Voltage
  • Dropout Voltage : 0.45V (typ.) at 250mA when VOUT ≥ 3V
  • Support Fixed Output Voltage 0.9V, 1.05V, 1.2V, 1.5V, 1.8V, 1.9V, 2.5V, 2.7V, 2.8V, 2.9V, 3V, 3.3V
  • Stable with Ceramic or Tantalum Capacitor
  • Current Limit Protection
  • Over Temperature Protection
  • TSOT-23-5 Packages Available
Datasheet
TitleLast UpdateShareDownload
30μA IQ, 250mA Low-Dropout Linear Regulator2015/09/21
Technical Documents
TitleLast UpdateShareDownload
Power IC Solutions for IoT/Portable/Wearable/Battery-Powered Applications2018/11/15
Part NumberPackage TypePackage Qty.Free SampleBuy From Authorized Distributor
RT9083-10GJ5TSOT-253000 Request Buy from Distributor
RT9083-33GJ5TSOT-253000 Not available Buy from Distributor
RT9083N-09GJ5TSOT-253000 Not available Buy from Distributor
