Low-Power, Integrated ECG/PPG AFE for Heart-Rate Monitoring and Measurements


Update Alert Share

The RT1025 is an integrated AFE solution for Heart-Rate monitoring and measurements. The RT1025 integrates low noise voltage and current sensing channels and is capable of sensing ECG (Electrocardiography) and PPG (Photoplethysmography) simultaneously. The RT1025 have > 100dB dynamic range and can sense pulses accurately by detecting the heart’s electric signals. The sampling rates of the high-precision voltage and current sensing channels in the RT1025 are configurable between 64 to 4kHz. The RT1025 solution need only few discrete components and is easy to use for low-power medical ECG/PPG, sports, and fitness applications. With high levels of integration and high-precision voltage and current sensing channels, the RT1025 solution is suitable for scalable medical instrumentation systems.The RT1025 is available in a 3.1mm x 3.4mm, 41-Ball, 0.4mm pitch, WL-CSP package


  • Medical Instrumentation (ECG) including :
    ► Heart Rate, Respiration, and Single-Lead ECG
  • Medical Instrumentation (PPG) including :
    ► Optical Heart-Rate Monitoring (HRM)
    ► Heart-Rate Variability (HRV)
    ► Pulse Oximetry (SpO2 Measurement)
    ► VO2 Max
  • Sports and Fitness Wearable Devices
  • High-Precision, Simultaneous, Multichannel Signal Acquisition
  • Internet of Things
Design Tool
TitleLast UpdateShare
RT1025 Evaluation Board Design Notice2019/09/11
Part NumberPackage TypePackage Qty.Free SampleBuy From Authorized Distributor
RT1025WSWL-CSP3.10x3.48-412000 Request Buy from Distributor
