2A, 6V, 1.5MHz, 25μA IQ, ACOT™ Synchronous Step-Down Converter

RT5785A/RT5785B

Update Alert Share

The RT5785A/B is a high-performance, Advanced Constant On-Time (ACOTTM) monolithic synchronous step-down DC-DC converter that can deliver up to 2A output current from a 2.5V to 6V input supply. The proprietary ACOT control architecture features quick transient response and provides stable operation with small ceramic output capacitors and without complicated external compensation. The switching ripple voltage is easily smoothed_out by small package filtering elements due to a constant switching frequency of 1.5MHz and the maximum duty cycle of 100% allows the device to operate at low dropout use. With internal low on-resistance power switches and extremely low quiescent current, the RT5785A/B displays excellent efficiency and good behavior across a range of applications.

Cycle-by-cycle current limit provides protection against shorted outputs, input under-voltage lock-out, output under-voltage protection, and thermal shutdown provide safe and smooth operation in all operating conditions. The RT5785A/B is available in the TSOT-23-8 (FC) package.

Applications

  • Mobile Phones and Handheld Devices
  • STB, Cable Modem, and xDSL Platforms
  • WLAN ASIC Power / Storage (SSD and HDD)
  • General Purpose for POL LV Buck Converter
  • Internet of Things
Key Spec.
RT5785A RT5785B
Status Active Active
Vin (min) (V) 2.5 2.5
Vin (max) (V) 6 6
Number of Outputs 1 1
Vout (min) (V) 0.6 0.6
Vout (max) (V) 5 5
Output Adj. Method Resistor Resistor
Iout (max) (A) 2 2
Current Limit (typ) (A) 2.5 2.5
Freq (typ) (kHz) 1500 1500
Ext Sync No No
Ron_HS (typ) (mOhm) 100 100
Ron_LS (typ) (mOhm) 60 60
Iq (typ) (mA) 0.025 0.025
Features ACOT Control;OCP;PSM;Power Good;UVP ACOT Control;Force PWM;OCP;Power Good;UVP
Package Type TSOT-28(FC) TSOT-28(FC)
Features
  • Dramatically Fast Transient Response
  • Steady 1.5MHz ±200kHz Switching Frequency
  • Very Low Input Quiescent and Shutdown Currents
  • Advanced COT Control Loop Design
  • Optimized for Ceramic Output Capacitors
  • 2.5V to 6V Input Voltage Range
  • Accurate Voltage Reference 0.6V ±2%
  • Integrated 100mΩ/60mΩ MOSFETs
  • Internal Start-Up into Pre-Biased Outputs
  • Power Good Indicator
  • Enable Control
  • Over-Current and Over-Temperature Protections
  • Under-Voltage Protection with Hiccup Mode
  • RoHS Compliant and Halogen Free
Datasheet
TitleLast UpdateShareDownload
2A, 6V, 1.5MHz, 25μA IQ, ACOT™ Synchronous Step-Down Converter2015/11/24
Technical Documents
TitleLast UpdateShareDownload
ACOT™ Stability Testing2019/03/18
ACOT™ (Advanced Constant-On Time) Synchronous Step-Down Converters2018/11/15
Power IC Solutions for IoT/Portable/Wearable/Battery-Powered Applications2018/11/15
Comparing Buck Converter Topologies2018/09/20
Buck Converter Selection Criteria2016/08/04
The Calculation of Output DC Offset for ACOT™ Control Buck Converter with Feed-forward Compensator2016/07/07
Videos
TitleLast UpdateShareViews
How to estimate control loop bandwidth from the transient response time?2017/03/30 617
Evaluation Boards
TitleLast UpdateShareDownload
2A, 6V, 1.5MHz, 25µA IQ, ACOT™ Synchronous Step-Down Converter2018/11/08
Reference Design
TitleLast UpdateShareDownload
Richtek Load Transient Tool2019/01/09
Part NumberPackage TypePackage Qty.Free SampleBuy From Authorized Distributor
RT5785AGJ8FTSOT-28(FC)3000 Request Buy from Distributor
RT5785BGJ8FTSOT-28(FC)3000 Not available Buy from Distributor
