The RT8077 is a high efficiency synchronous, step-down DC/DC converter. Its input voltage range is from 2.6V to 5.5V and provides an adjustable regulated output voltage from 0.8V to 5V, while delivering up to 2A of output current. The internal synchronous low on-resistance power switches increase efficiency and eliminate the need for an external Schottky diode. The switching frequency is set by an external resistor or can be synchronized to an external clock. The 100% duty cycle provides low dropout operation extending battery life in portable systems. Current mode operation with external compensation allows the transient response to be optimized over a wide range of loads and output capacitors. The 100% duty cycle in Low Dropout Operation further maximize battery life. The RT8077 is available in the WDFN-8L 2x2 package.
High Efficiency : Up to 95%
Low RDS(ON) Internal Switches : 90mΩ
Programmable Frequency : 300kHz to 2MHz
No Schottky Diode Required
0.8V Reference Allows for Low Output Voltage
Low Dropout Operation : 100% Duty Cycle
2.6V to 5.5V Input Voltage Range
VOUT Range from 0.8V to 5V
Up to 2A Output Current
Thermal Shutdown
RoHS Compliant and Halogen Free
